Zoho Payments Integration (Backend)

If you've landed here because you Googled "Zoho Payments integration" and found three outdated forum posts and a wall of reference docs with no working example, same. This is the article I needed a few weeks ago, written after actually shipping a real integration: an appointment-booking backend that takes payment before confirming a slot.

Zoho Payments works fine once it's wired up. Getting there is the hard part, mostly because the docs describe endpoints, not flows, and a few of the gotchas below cost real debugging hours. This is the flow, the code, and, more usefully, the exact mistakes to skip.

The mental model first

Before any code, understand that Zoho Payments needs two separate, unrelated credentials, and almost every early confusion traces back to mixing them up:

The API key you see front-and-center on the Zoho Payments dashboard is not enough to create a payment session from your server. That single misunderstanding is where most first attempts stall out. Server-side calls need an OAuth access token, obtained via a refresh token you generate once.

The full flow, end to end

1. Patient/customer clicks "Pay"
        │
        ▼
2. Your backend calls Zoho: "create a payment session"
   (needs OAuth access token)
        │
        ▼
3. Zoho returns a payments_session_id
        │
        ▼
4. Your frontend opens Zoho's checkout widget
   using that session_id + your API key
        │
        ▼
5. Customer pays (card/UPI/whatever)
        │
        ▼
6. Zoho sends a WEBHOOK to your backend, server-to-server
   ("payment.succeeded" / "payment.failed")
        │
        ▼
7. Your backend verifies the webhook signature,
   then updates your database (order paid, booking confirmed, etc.)

Step 6 is the one people skip in their mental model and then get bitten by. The frontend widget resolving successfully is not proof of payment. It's a nice-to-have for immediate UI feedback, but the webhook is your actual source of truth: it's signed, server-to-server, and can't be spoofed by a browser. Design your backend so nothing important (marking an order paid, confirming a booking) happens until the webhook says so.

Part 1: The one-time OAuth setup

This is the part with no good existing writeup, so here it is in full.

Step 1: Register an ORG-scoped OAuth client

Most Zoho tutorials tell you to register your app through the regular "Add Client" page. Don't use that one for Zoho Payments. It needs a different, special version of that same page, made specifically for payments.

https://api-console.zoho.in/add?client_type=ORG

(Swap .in for .com, .eu, etc. depending on your Zoho data center. More on this below.)

Fill in a Client Name, Homepage URL, and a Redirect URI. The redirect URI doesn't need to be a real, functioning page. You'll only use it once, manually, to read a code out of the browser's address bar. Register it, and you get a Client ID and Client Secret.

Step 2: Get an authorization code

Build this URL (all values are yours from Step 1, plus your Zoho Payments account_id, visible in your dashboard's Account Details):

https://accounts.zoho.in/oauth/v2/org/auth?
  scope=ZohoPay.payments.CREATE,ZohoPay.payments.READ
  &client_id=YOUR_CLIENT_ID
  &soid=zohopay.YOUR_ACCOUNT_ID
  &response_type=code
  &redirect_uri=YOUR_REDIRECT_URI
  &access_type=offline

Open it in a browser, log in as an Account Owner/Admin, and approve the consent screen. You'll get redirected with ?code=... in the URL. Copy it immediately, because it expires in about 60 seconds.

Step 3: Exchange the code for a refresh token

curl -X POST "https://accounts.zoho.in/oauth/v2/token?code=THE_CODE&client_id=YOUR_CLIENT_ID&client_secret=YOUR_CLIENT_SECRET&redirect_uri=YOUR_REDIRECT_URI&grant_type=authorization_code"

The response includes a refresh_token. This is the only value you actually need to keep. It doesn't expire on a timer. Save it to your environment config, and your backend will use it forever to mint fresh access tokens as needed.

⚠️ The soid parameter is easy to miss and undocumented in most walkthroughs. Without it, you'll get a cryptic invalid_client error even with a perfectly valid client. It's what tells Zoho this is an organization-level auth request, not a personal one.

Part 2: The backend code

Here's a minimal, working Zoho Payments client module (Node/Express, but the shape translates to any backend). cache is whatever cache you use (Redis, an in-memory map), and parseWebhookEvent and handlePaymentEvent further down are your own code.

import axios from 'axios';
import crypto from 'node:crypto';

const paymentsHttp = axios.create({
  baseURL: process.env.ZOHO_PAYMENTS_BASE_URL,
  // set this to your regional Zoho Payments API base, e.g. payments.zoho.in/api/v1
});

const accountsHttp = axios.create({
  baseURL: process.env.ZOHO_ACCOUNTS_BASE_URL,
  // set this to your regional Zoho accounts base, e.g. accounts.zoho.in
});

// --- OAuth: exchange refresh token for a fresh access token ---
async function getAccessToken() {
  const cached = await cache.get('zoho:access_token');
  if (cached) return cached;

  const { data } = await accountsHttp.post('/oauth/v2/token', null, {
    params: {
      refresh_token: process.env.ZOHO_REFRESH_TOKEN,
      client_id: process.env.ZOHO_CLIENT_ID,
      client_secret: process.env.ZOHO_CLIENT_SECRET,
      grant_type: 'refresh_token',
    },
  });

  // IMPORTANT - see gotcha #2 below before trusting expires_in blindly
  const ttl = Math.min(Math.max((data.expires_in || 3600) - 120, 60), 3600);
  await cache.set('zoho:access_token', data.access_token, ttl);
  return data.access_token;
}

// --- Create a payment session ---
export async function createPaymentSession({ orderId, amount, currency, invoiceNumber }) {
  const token = await getAccessToken();

  const { data } = await paymentsHttp.post(
    '/paymentsessions',
    {
      amount: Number(amount),
      currency,
      expires_in: 600, // seconds, Zoho's allowed range is 300-900
      invoice_number: invoiceNumber,
      meta_data: [{ key: 'orderId', value: String(orderId) }], // your own reference, see gotcha #3
    },
    {
      params: { account_id: process.env.ZOHO_ACCOUNT_ID },
      headers: { Authorization: `Zoho-oauthtoken ${token}` },
    }
  );

  const session = data.payments_session;
  return {
    paymentsSessionId: session.payments_session_id,
    amount: session.amount,
    currency: session.currency,
  };
}

// --- Verify a webhook came from Zoho ---
export function verifyWebhookSignature(rawBody, signatureHeader) {
  if (!signatureHeader) return false;

  const parts = Object.fromEntries(
    signatureHeader.split(',').map((kv) => kv.split('='))
  );
  const { t: timestamp, v: providedSignature } = parts;

  const age = Date.now() - Number(timestamp);
  if (age < 0 || age > 5 * 60 * 1000) return false; // reject anything older than 5 min

  const expected = crypto
    .createHmac('sha256', process.env.ZOHO_SIGNING_KEY)
    .update(`${timestamp}.${rawBody}`)
    .digest('hex');

  const a = Buffer.from(providedSignature);
  const b = Buffer.from(expected);
  return a.length === b.length && crypto.timingSafeEqual(a, b);
}

The frontend widget

The backend hands the frontend a paymentsSessionId. The frontend does the rest with your API key (not any OAuth credential):

<script src="https://static.zohocdn.com/zpay/zpay-js/v1/zpayments.js"></script>
<script>
  const instance = new window.ZPayments({
    account_id: 'YOUR_ACCOUNT_ID',
    domain: 'IN', // or US/EU per your data center
    otherOptions: { api_key: 'YOUR_API_KEY' },
  });

  instance.requestPaymentMethod({
    amount: '299.00',
    currency_code: 'INR',
    payments_session_id: sessionIdFromYourBackend,
  });
</script>

The webhook handler

The part that actually matters for correctness:

app.post('/payment/webhook', async (req, res, next) => {
  const signatureHeader = req.headers['x-zoho-webhook-signature']; // exact header, see gotcha #4
  const rawBody = req.rawBody; // see gotcha #5 - this must be the EXACT raw bytes

  if (!verifyWebhookSignature(rawBody, signatureHeader)) {
    return res.status(401).json({ success: false });
  }

  const event = parseWebhookEvent(req.body);
  await handlePaymentEvent(event); // your own DB update logic

  return res.status(200).json({ success: true });
});

Two setup details this snippet assumes, both easy to miss:

// In your Express app setup - you need the RAW bytes, not the
// re-serialized object, or signature verification will always fail.
app.use(express.json({
  verify: (req, res, buf) => { req.rawBody = buf; }
}));

Gotchas that will cost you real time (learn from mine)

1. Data-center mismatch gives invalid_client

Zoho segregates accounts and OAuth clients by data center (.com, .in, .eu, .com.au). A client registered at api-console.zoho.com simply does not exist if you authenticate against accounts.zoho.in. If you get invalid_client and you're sure your credentials are right, this is almost always it. Match the console domain to the domain your Payments account actually lives on.

2. expires_in may come back in milliseconds, not seconds

Standard OAuth convention is seconds. In testing, I received expires_in: 3600000, which, read as seconds, means "cache this token for 41 days." A stale token then silently breaks every payment attempt until someone notices and manually clears the cache. Always clamp your cache TTL to a hard ceiling (Math.min(yourCalculatedTtl, 3600)), regardless of what the API claims. Defensive code here is cheap insurance.

3. Don't trust reference_number if you share a Zoho account across products

If more than one system in your company uses the same Zoho Payments account (common: one account, multiple products), Zoho fires every webhook event to every registered webhook URL, regardless of which system created the payment. Filter by something only you set, your own meta_data key, never by reference_number, which other systems can and will populate with their own differently-shaped values. Skip (return 200 OK, don't process) anything without your expected meta_data key instead of erroring. Otherwise you'll flood your own logs with "failed" webhook deliveries for events that were never yours to handle.

4. The signature header is X-Zoho-Webhook-Signature, not X-Zoho-Signature

Easy typo, and unless you go looking, nothing tells you it's wrong. verifyWebhookSignature just quietly returns false for a missing header, which looks identical to a genuine signature mismatch.

5. Raw body capture is mandatory

JSON.stringify(req.body) is not a valid substitute. HMAC signatures are computed over exact bytes. If your body-parsing middleware doesn't capture the raw buffer before parsing, and your webhook handler falls back to re-serializing the already-parsed object, you'll get a different byte sequence than what was signed. Verification fails, even with the correct signing key. This bug is sneaky because everything else looks right.

6. Your account-level signing key and your per-webhook signing key can be different

If you configure a webhook subscription individually (rather than using a single account-wide setting), check whether that specific subscription has its own signing key separate from the general one shown on your main dashboard. Using the wrong one produces a signature that's structurally valid (right length, right format) but numerically completely different. If you're debugging blind, that looks identical to "everything's broken" rather than "one specific value is wrong."

7. event_id ≠ payment_id ≠ transaction_reference_number

Three different identifiers show up in a webhook payload, and it's easy to grab the wrong one:

• event_id identifies this webhook delivery, not the payment. It can repeat across retries.
• payment_id is Zoho's own internal ID for the actual transaction. Good for calling Zoho's API back.
• transaction_reference_number is the underlying bank/UPI network's own reference. Good for reconciliation against a bank statement or a customer support query ("I paid but it's not showing").

Store whichever one you'll actually need to look something up by later, possibly both.

Testing without burning real transactions

Zoho has a genuine sandbox environment (paymentssandbox.zoho.in), but it's not self-serve. You need to request it from Zoho support to get it enabled. Once enabled, the OAuth flow is nearly identical, with two differences:

• The scope prefix changes from ZohoPay. to ZohoPaySandbox.
• You need a soid=zohopaysandbox.{sandbox_account_id} parameter instead

If sandbox access isn't available yet, testing with tiny real amounts (₹1–2) against live mode works fine for verifying the full flow end-to-end. Just be aware live_mode: true will show up in your webhook payloads.

For local development, a devtunnel/ngrok-exposed local server works for receiving real webhooks. Remember that tunnel URLs are usually session-based and die when your terminal closes, so you'll need to re-register the webhook URL in Zoho's dashboard if it changes.

The short version, if you skip everything else

• API key ≠ OAuth credentials. You need both, for different halves of the flow.
• The webhook, not the frontend widget's return value, is your source of truth.
• Match your OAuth client's data center to your account's data center.
• Clamp your token cache TTL defensively. Don't trust expires_in's unit blindly.
• Capture the raw request body before your JSON parser touches it.
• If your Zoho account is shared across products, filter webhooks by your own meta_data, never by reference_number.
• The webhook signature header is X-Zoho-Webhook-Signature.

Hopefully this saves the next person the debugging cycles it took to write it.
